Overview
Quick Details
- Place of Origin:
-
Beijing, China
- Brand Name:
-
Vmaxpower
- Model Number:
-
SuninvM HF-Pro 3KW
- Type:
-
DC/AC Inverters
- Output Type:
-
Single
- Output Current:
-
60A
- Output Frequency:
-
50/60Hz
- Size:
-
100*300*440mm
- Weight:
-
12kgs
- Certificate:
-
CE, CE ISO9001
- Product name:
-
Batteryless Off Grid Solar Inverter
- Application:
-
Solar Power System Home
- Warranty:
-
2 Years
- Output waveform:
-
Pure Sine Wave Output
- Display:
-
LCD Display
- Inverter type:
-
Off-grid Inverter
- Protection:
-
Overload
- Rated power:
-
3000VA/3000W
- Item:
-
Dc Ac Solar Inverter
| MODEL | SuninvM HF-Pro 3KW |
| Rated Power | 3KVA/3KW |
| Max.PV Array Power | 4000W |
| Nominal PV Voltage | 240VDC |
| PV Array Mppt Voltage Range | 120-450VDC |
| Max.PV Array Open Circuit Voltage | 500VDC |
| Max.Charging Current(AC+solar) | 80Amp |
| AC INPUT(AC) | 220V |
| System Voltage | 48VDC |
| Nominal Input Voltage | 230VAC |
| Nominal Input Frequency | 50Hz/60Hz(Auto detection) |
| Transfer Time | 10ms typical(UPS0 ; 20ms typical(Appliances) |
For your off-grid photovoltaic system, you should choose 3000W～5000W Hybrid Inverter with MPPT Controller according to the load. Package & Shipping
Batteries have high requirements for transportation.
For questions about sea transportation, air transportation and road transportation, please consult us.
Multifit Office-Our Company
HQ located in Beijing, China and founded in 2009 Our factory located in 3/F,JieSi Bldg.,6 Keji West Road,Hi-Tech Zone,Shantou,Guangdong,China.
Multifit was founded in 2009...
Guess what you want to know
Company Qualification
Note: Inverter output power must be greater than the use of electrical power, especially for the start of large power electrical appliances, such as refrigerators, air conditioning, but also leave some more allowance.
I am willing to be a new partner
Customer feedback is very good product
One-stop service
smiling service
Dixere certis. Uno praebebat. Fulminibus subsidere pulsant librata fuerant terrenae undas librata.
Homini locavit fluminaque calidis metusque. Fuit haec madescit
Photovoltaic leader
Pleasant cooperation
We are long-term partners
Long-term business
quality assurance
vmaxapower brand products, worthy of my trust
Do things with integrity
We will do better
Installation of photovoltaic system connection line:
It is recommended to use a wire slot, which will look neat
| Technica Data SuninvM HF-Pro | MODEL | SUN INVM HF - Pro 3KW | SUN INVM HF- Pro5KW | | Rated Power | 3KVA/3KW | 5KVA/5KW | | PV INPUT (DC) | | Max. PV Array Power | 4000 W | | Nominal PV Voltage | 240VDC | | PV Array MPPT Voltage Range | 120～450VDC | | Max. PV Array Open Circuit Voltage | 500VDC | | Max.Charging Current(AC + solar) | 80Amp | | AC INPUT(AC) | | Nominal Input Voltage | 230VAC | | Low Loss Voltage | 170VAC±7V(UPS)；90VAC±7V(Appliances) | | Low Loss Return Voltage | 180VAC±7V(UPS)；100VAC±7V(Appliances) | | High Loss Voltage | 280VAC±7V | | High Loss Return Voltage | 270VAC±7V | | Max. AC Input Voltage | 300VAC | | Nominal Input Frequency | 50Hz/60Hz (Auto detection) | | Transfer Time | 10ms typical(UPS)；20ms typical(Appliances) | | BATTERY MODE OUTPUT (AC) | | Nominal Output Power | 3KVA/3KW | 5KVA/5KW | | Surge Power | 6000VA | 10000VA | | Nominal Output Voltage | 230VAC±5% | | Output Waveform | Pure Sinewave | | Efficiency (DC to AC)(Peak) | 93% | | UTILITY CHARGER | | Nominal DC Voltage | 24VDC | 48VDC | | Maximum Charging Current | 60Amp | | Bulk Charging Voltage | Flooded Battery | 29.2VDC | 58.4VDC | | AGM/Gel Battery | 28.2VDC | 56.4VDC | | Floating Charging Voltage | 27VDC | 54VDC | | OverCharge Protection | 33VDC | 63VDC | | GENERAL | | PHYSICAL | | Dimension, D× W × H (mm) | 100 × 300 × 440 | | Net Weight (kgs) | 9 | 10 | | Communication Port | RS-232/USB | | ENVIRONMENT | | Humidity | 5 ~ 95% RH (Non condensing) | | Operating Temperature | -10 to 55°C | | Altitude | 0 ~ 1000 m | |
Key Features ●Output Power factor 1.0 ●The PV input range is wide which is up to 500VDC ●It can work without battery ●Pure sine wave inverter ●Selectable AC input voltage range for home appliances and personal computers ●AC/Solar input priority (Optional) ●Compatible with mains voltage or generator power ●Auto restart while AC is recovering ●Multiple protection ●Smart battery charge design for optimized battery performance Cold start function
Own brand "MULTIFIT" & "Vmaxpower" go to show on all the exhibition about solar power and energy in China and other countries every year.
Multifit Solar Inverter has had certificates
Q1: Are you a factory or trading company? A: We are a factory. Multifit Solar is an original design manufacturer of power inverter, the solar charge controller and solar array box since 2009. Q2: Where is your factory located? How can I visit there?
A: Our factories are located in BeiJing and Shantou City, Guangdong, China. Its takes half hours from Airport or Train Station. Welcome to visit our technology development and production lines at your free time! Q3: How can I get some samples?
A: We can provide you samples for quality checking. Kindly contact us for getting more discount and profitable project solutions. Q4: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. Airline and sea shipping also optional. Q5: Where is your loading port?
A: Multifit have 2 factories in Beijing and Shantou City Guangdong. The loading port is TianJin/ Shanghai or Shenzhen/ Guangzhou for optional. Q6: How long is your factory delivery time?
A: 3-7 days for sample order, 5-10 days for MOQ order,15-30 days for 20ft container. Q7: Is it OK to print my logo on the product?
A: Yes. Please inform us formally before production and confirm the design firstly based on our sample. Q8: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
